Automated Logic WebCTRL driver for Jace 8000 - Supervisor



Our ALC driver for Tridium Niagara communicates with ALC controllers indirectly via WebCTRL server – the standard front-end software deployed on virtually every Automated Logic BMS site. It provides access to the data in all connected controllers, ALC and third-party BACnet ones, as well as legacy ALC CMnet communication protocol.

The driver allows to automatically discover devices and points, import points into Niagara station, read point values, and write into them. Points retain their names, types, and unit facets, which greatly simplifies the integration process. Trendlogs could also be periodically imported from WebCTRL into Niagara.

The driver might be deployed in JACE or in Niagara Supervisor, which could reside either locally on-site, or on remote premises, or on a cloud.

Key features
Communicates with Automated Logic WebCTRL software via HTTPS
Allows to access controllers connected to WebCTRL
Supports both current ALC lines (ME, SE, ZN) and legacy ones (M, S, U)
Enables point read and write
Implements automatic device and point discovery
Imports trendlogs
Ideal for retrofit applications

Automated Logic WebCTRL drivers available
  • Automated Logic WebCTRL for Jace 8000 / 250 points
  • Automated Logic WebCTRL for Jace 8000 / 1000 points
  • Automated Logic WebCTRL for Jace 8000 / Unlimited
  • Automated Logic WebCTRL for Supervisor
  • Automated Logic WebCTRL for Supervisor / extra 500 points
